MDT Range

The Irrimec Master range of irrigators all have hydraulically operated wheel “raising and lowering”. This design lowers the centre of gravity and allows longer lengths of hose with very good stability.

On Master MDT models, the drum is driven on both sides (master double traction). Two very large diameter drive rings are driven by unique roller sprockets on both sides without chains around the drum to stretch.

Standard features for MDT models sold in the UK are as indicated below:

  • Large diameter drive rings on both sides of the drum
  • Turntable lowers to the ground and allows 360 degree rotation
  • Very large wheels – hydraulically raised or lowered



FrameModels AvailableStandard Options
MDT8110 / 500
110 / 580
110 / 600
110 / 650
- Drive on both sides of drum
- Hose connection both sides
- Electric auto shut off
- Dosidis
- Alternator charging
- Full hydraulics for turntable / trolley / legs / wheels
- Konkord gun
MDT11110 / 850
135 / 770
- Drive on both sides of drum
- Hose connection both sides
- Electric auto shut off
- Dosidis
- Alternator charging
- Full hydraulics for turntable / trolley / legs / wheels
- Konkord gun
- Air compressor
